Indoor SMD LED Displays

Cost-Effective Performance. Brilliant Visuals.

Indoor SMD LED displays deliver vivid colour reproduction, high reliability, and strong value, built on proven Surface-Mounted Device technology in lightweight panels suited for corporate lobbies, retail environments, control rooms, and broadcast studios.

● Pixel pitches from P1.25 to P4.0
● Brightness up to 1,000 nits
● Seamless die-cast aluminium cabinets
● Lightweight, easy-to-install construction
● Refresh rates up to 3,840Hz, flicker-free
● Easy component-level repair on-site

Download Brochure

Product Enquiry

Proven & Cost-Effective

The most widely deployed LED packaging method, offering strong performance and value across pixel pitches.

Lightweight Construction

Individual SMD lamp packages simplify installation and reduce structural load for wall-mounted or suspended displays.

Wide Pixel Pitch Range

Available from P1.25 through P5 and beyond, from close-viewing rooms to large-format signage.

Easy Component-Level Repair

Individual LED lamp beads can be resoldered or replaced on-site, keeping maintenance low and downtime short.

High Refresh Rate

Refresh rates from 1,920Hz to 3,840Hz deliver flicker-free output for broadcast and video conferencing.

Broad Compatibility

Works with all mainstream LED control systems, with no proprietary lock-in.

Vivid Colour Reproduction

Brightness up to 1,000 nits ensures vibrant, high-clarity visuals.

Seamless Cabinet Design

Die-cast aluminium cabinets deliver a smooth, uniform display surface.

Versatile Deployment

Suited for corporate lobbies, retail environments, control rooms, and broadcast studios.

Product Technology	SMD (Surface-Mounted Device)
Pixel Pitch	1.25 / 1.53 / 1.86 / 2.0 / 2.5 / 3.0 / 4.0 mm
Standard Module Size	320 × 160 mm
Cabinet Material	Die-cast Aluminum
Cabinet Size	640 × 480 mm
Refresh Rate	≥ 1920 Hz (up to 3840 Hz available)
Brightness	600 – 1,000 nits
Viewing Angle (H/V)	160° / 160° or 140° / 140°
Contrast Ratio	≥ 4,000:1
Maintenance Method	Front & Rear Access
Input Voltage	AC 100–240 V, 50/60 Hz
Operating Temperature	–20°C to +60°C
Operating Humidity	10%–90% RH
Lifespan	≥ 100,000 hours
Control System	Synchronous (NovaStar, Colorlight, Linsn)
